Switch x256
Switch
x16
Position and # of
points
Always 1
A 16
points
1
1
Switch
x1
A 32
points
2
1
Module
type
B 16
points
3
1
Form C
relays
1
B 32
points
4
1
24 V
sinking
2
C 16
points
5
1
4-20 mA
3
C 32
points
6
1
24 V
sourcing
4
If none of these steps help resolve the fault please contact DOD Technologies Inc. technical support for
further assistance.
Hardware Replacement:
Optic Block Replacement:
To replace a CL96 optic block the following tools will be needed:
1. #1 Phillips screwdriver
2. #2 Phillips screwdriver
3. #1 standard screwdriver
To replace a CL96 optic block, follow these steps:
1. Open the gate
2. Remove power from the analyzer by unplugging the green connector.
