Domino F720i

OPERATION
EPT031055 Issue 2 September 2017 3-5
F-SERIES LASER MARKING SYSTEM
Optional
Touchpanel
Laser Key
Switch
On/Off Switch
Laser Lens
Scanner
Head
Mains
Connector
Laser Head
Laser Fibre
Controller
X28 Connector
Water In
(Cold) (max. 5 bar)
Water Out
Water To Laser
(Hot)
Factory fitted option for
water cooling
X28 Connection
