INSTALLATION INSTRUCTIONS
EPT031055 Issue 2 September 2017 2-5
Scanner Fields and Distances
All values may fluctuate up to 5%. All values in millimeters.
Removal of the transport locking device
i-Tech 10mm Scanner
Focal Length
Maximum
Field
Usable
Field
Working
Distance
160 127x121
118 x 118 190
250 198x195 187x187 276
300 244x238 229 x 229 331
CAUTION: The beam output lens is protected by a
transport locking and dust protection cap
to prevent damage or external soiling that
will cause a reduction in laser
performance. Remove this device without
fail before operation.
