TECHNICAL REFERENCE

EPT031055 Issue 2 September 2017 4-3

CONTROL UNIT

CONTROL UNIT WITH COOLING OPTION

Controller (IP55)

(based on BCP7

Controller)

Laser Fibre

Controller

(based on BCP7

Controller)

Factory fitted

cooling option
