OPERATION
EPT031055 Issue 2 September 2017 3-29
CREATING AND EDITING A MESSAGE
Add Text
(1) Select Messages > New Message or Settings > Message Editor to
open the Message Editor.
(2) Press on the screen within a specific area of the Message Editor
where you require the item to appear. A cross hair will appear at this
location.
(3) Select the Add icon.
(4) The Add sub-menu displays.
(5) From the sub-menu select the Text icon.
Note: Change keyboards by selecting the appropriate Alternative
Keyboard icon at the bottom of the text entry screen.
(6) Enter the required text using the keyboard and select the green tick
icon when finished.
(7) To change text, select the text item and then the Keyboard icon on the
Edit sub-menu.
(8) To change text parameters (Object Name, Position, Bold, Width, etc.),
use the sub-menu (Font, Alignment) or select More…
(9) To delete an object, select the object and select the delete icon of
the Edit menu.
(10) Activate the message for printing by sending it to the printer via
the File menu .
Text Barcode
(MERC)
Image Arc
Rectangle
Clone
Item
To Next Page
