Domino F720i

To Next Page

To Previous Page

OPERATION

3-8 EPT031055 Issue 2 September 2017

Power supply LEDs on

the front of the laser

Shutter LEDs on the front of the laser

(only with shutter option)

Lights when shutter is open

To scanner head
