Domino F720i

To Next Page

To Previous Page

TECHNICAL REFERENCE

EPT031055 Issue 2 September 2017 4-11

F-Series

Scanner Long Mount Orientations

axial-down

left-down

down-left

axial-left

axial-right

right-down

down-right
