MAINTENANCE AND FAULT FINDING
5-28 EPT031055 Issue 2 September 2017
On the ETX base board:
Name Colour Location Function
V1 green ETXB-PCB FPGA Hardware-Design loaded
V2 yellow ETXB-PCB HDD Activity
V3 green ETXB-PCB 5V present
V4 green ETXB-PCB 3.3V present
V5 green ETXB-PCB 2.5V present
V6 green ETXB-PCB 1.26V present
V7 red ETXB-PCB ETH 1 Link
V8 green ETXB-PCB ETH 1 Speed (10/100 MBit)
V9 yellow ETXB-PCB ETH 1 Activity
V10 yellow ETXB-PCB ETH 2 Link
V11 red ETXB-PCB ETH 2 Speed (10/100 MBit)
V12 green ETXB-PCB ETH 2 Activity
V13 green ETXB-PCB DSP application loaded
