INSTALLATION INSTRUCTIONS
2-60 EPT031055 Issue 2 September 2017
To extend the marking field in Dynamark 3, move the object in the opposite
direction to the movement outside the marking field.
Marking starts as the product marking field enters the marking area.
Note: Moving the mark on the screen, whether in the real or extended
fields, can move the mark on the product. First set the ideal
position of the mark on the screen, then adjust the product
detector (print go) or change the encoder delay to set the actual
mark position onto the product.
Marking area
Product
Marking field on product
Product movement direction
