DoorKing 4302 - Wiring the Solar Control Box; Control Box Overview

4302-067-G-2-21
10
2.1 Control Box Overview
SECTION 2 - WIRING
Since building codes vary from city to city, we highly recommend that you check with your local building department prior to
installing any permanent wiring to be sure that all wiring to the solar control box complies with local code requirements.
Conduit Not Supplied
12 V
Battery
12 V
Battery
F2 F1
S1 S2 A B
CH1
SW1
LOOP 1
CH1
9416-010
1 Channel
ON DIP
1234
1 2 3 4 5 6 7 8 9 1011 1213141516171819 20
ON
OFF
PUSH TO OPERATE
technician use only
Solar NEG
Solar POS
24 V POS
24 V NEG
Relay COM
Relay N.O.
Full Open
Not Used
Not Used
B
Solar Power Input
See page 19.
Circuit Board Terminal
Battery Plug
See page 18.
Batteries
See page 18.
PRIMARY Operator
Connection ONLY
See page 11.
SECONDARY Operator
Connection ONLY
See page 11.
FULL
OPEN
OB
CB
Close
Beam
Open
Beam
GND
GND
SW1
1
ON
2
1476-010
P
U
SH
te
c
LOOP
9
41
6
-
0
1
0
1
C
hannel
“Optional”
8040-080 DKS
Low Current Draw
Radio Receiver
and Antenna
See pages 15 & 27-29.
“Optional” Coaxial Cable
Antenna Kit
Increases signal range P/N 1514-073
15 ft Cable
Full Open
Terminal
See page 15.
Power
Terminal
See page 19.
Power Switch
See page 19.
Diablo
Controls, Inc.
Stuck in traffic for over 37 years!
NC COM
RELAY
10 to 30 Volts
AC or DC
POWER DETECT
DSP-7
POWER LOOP
COM
+
NO
REMOVE CONNECTOR TO RESET
Diablo
Controls, Inc.
Stuck in traffic for over 37 years!
NC COM
RELAY
10 to 30 Volts
AC or DC
POWER DETECT
DSP-7
POWER LOOP
COM
+
NO
REMOVE CONNECTOR TO RESET
UL 325 Terminal
See page 12-14.
“Optional” External
Low Current Draw
Loop Detectors
See pages 15 and 17.
DoorKing 8080-057
Retro-Reflective Photocell
(Included) See pages 12 & 13.
“Optional” DKS Low Current Draw
Plug-In Loop Detector See page 16.
4302-018
