DoorKing 4302 - Table of Contents

4302-067-G-2-21
1
IMPORTANT
Solar Control Box Specifications
Swing Gate Requirements
ASTM F2200 Standard for Gate Construction
Important Safety Instructions
Instructions regarding intended installation:
Important Notices
UL 325 Entrapment Protection
Glossary
Previous Page
2-3
4
4
4
5
6
7
SECTION 2 - WIRING 10
10
11
12-14
15
16
17
18
19
2.1 Control Box Overview
2.2 Wiring Operators to 4302 Circuit Board
2.3 Entrapment Protection Wiring
2.4 Full Open & Circuit Board Terminals Wiring
2.5 DKS Plug-In Loop Detector (Reverse Loops ONLY)
2.6 External Loop Detector Wiring
2.7 Battery Wiring
2.8 Solar Panel Wiring
SECTION 1 - SOLAR PANEL INSTALLATION CONSIDERATIONS 8
8
9
1.1 Solar Panel Concerns BEFORE Installation
1.2 Solar Panel Positioning
IMPORTANT INFORMATION FOR OWNER
36
36
37
38
39
Shut-Off Power to Operator OR Shut-OFF Alarm
Manually Operating the Gate - NO Power
Gate Operator’s Monthly Check-Up
New Installation Checklist for Installer and Property Owner
Quick Guides
Quick Guide-1
Quick Guide-2
Quick Guide: DIP Switches
Quick Guide: Terminals Wiring
SECTION 4 - MAINTENANCE AND TROUBLESHOOTING 31
4.1 Maintenance
4.2 Diagnostics Check
4.3 Troubleshooting
4.4 Accessory Items
Solar Control Box Schematics
31
31-32
32-33
34
35
TABLE OF CONTENTS
SECTION 3 - ADJUSTMENTS 20
20
21-22
23-25
26
27-29
29-30
3.1 3402 Circuit Board Description and Adjustments
3.2 DIP-Switches
3.3 Limit Sensors Adjustment - Select your specific operator
6004 Limit Sensors ONLY
6006 Limit Sensors ONLY
6400 Limit Sensors ONLY
3.4 Inherent Reverse Sensor Adjustment
3.5 “Optional” Radio Receiver Model (8040-080)
3.6 Shutdown Conditions
Soft Shutdown
Hard Shutdown (Alarm Activated)
23
24
25
29
30
