2.4 Full Open & Circuit Board Terminals Wiring
Full Open Terminal Operation: When the circuit board is NOT in use (idle time), power is shut down to it. Power will
continue at the Full Open Terminal at all times. This allows an access control device - radio receiver, key switch,
exit loop or safety opening device to be activated at any time to open the gate. ANY access control device used
needs a relay contact time of AT LEAST 1 SECOND to bring the circuit board out of “idle time” and operate gate.
#1
#2
#3
Diablo
Controls, Inc.
Stuck in traffic for over 37 years!
NC COM
RELAY
10 to 30 Volts
AC or DC
POWER DETECT
DSP-7
POWER LOOP
COM
+
NO
REMOVE
CONNECTOR
TO RESET
Key Switch
(Dry contact)
Safety Opening
Device
(Dry contact)
Controls must be far
enough from the gate so
that the user is prevented
from coming in contact
with the gate while
operating them. Do not
wire any access control
devices to the circuit
board terminal.
Important: Low current draw
external loop detectors MUST be
used to minimize power drain on
batteries. Loop detectors MUST
have power at ALL times.
N.O.
Com
N.O.
Com
N.O.
Com
Com
Power
N.O.
Com
Power
123456
ON
OFF
PUSH TO OPERATE
technician use only
Solar NEG
Solar POS
24 V POS
24 V NEG
Relay COM
Relay N.O.
Full Open
Not Used
Not Used
Use 18 AWG min.
250 mA Maximum Power
Low Current Draw
Single Channel
External EXIT
Loop Detector
Low Current Draw
Single Channel
External REVERSE
Loop Detector
24 V Pos
Relay Com
Relay N.O.
12345
6
7
89
10 11 12
13
14 15
16 17 18 19
20
Circuit Board Terminal
Loops
wired in
series
P/N 9402-050
P/N 9402-050
Diablo
Controls, Inc.
Stuck in traffic for over 37 years!
NC COM
RELAY
10 to 30 Volts
AC or DC
POWER DETECT
DSP-7
POWER LOOP
COM
+
NO
REMOVE
CONNECTOR
TO RESET
Automatic Exit
Loop
Diablo
Controls, Inc.
Stuck in traffic for over 37 years!
NC COM
RELAY
10 to 30 Volts
AC or DC
POWER DETECT
DSP-7
POWER LOOP
COM
+
NO
REMOVE
CONNECTOR
TO RESET
External Loop detector
mounting position
Use existing
screws to mount
detector(s)
Reverse
Loop
Reverse
Loop
See page 17 for more
exit loop wiring information.
See page 17 for more
reverse loop wiring information.
OB
CB
GND
GND
1476-010
FULL
OPEN
24 V POS Terminal Note:
Exceeding 250 mA of power
from this terminal may cause
the circuit board transformer to
overheat, causing intermittent
problems.
#3 Circuit Board Terminal Note:
Exceeding 250 mA of power from this terminal may
cause the circuit board transformer to overheat,
causing intermittent problems.
DoorKing 8080-057
Retro-Reflective Photocell
Power ONLY
See page 12 to
wire relay to
Open Beam
OR Close Beam.
1 2 3 45
6
7
89
10 11 12
13
14 15
16 17 18 19
20
Circuit Board Terminal
Com
24 VAC
Standard Reverse
Com
1
2
3
4
5
6
7
8
Low Current
Draw Receiver
Type of wiring to be used
on ALL external devices:
A) Type CL2, CL2P, CL2R, or CL2X.
B) Other cable with equivalent or better
electrical,mechanical, and flammability ratings.
P/N 8040-080
Radio #1 Com (White)
Radio #2 Relay (Green)
Radio #3 Power (Red)
See pages 27-29 for
programming
Set for
Low
Power
Mode
Page 29
