Maintenance Section
-137-
Display for SCR Cleaning
As shown in the table below, for your information, we provide Information about correlation between Symbol and message
(Display).
No State SYMBOL Lamp Message on the Display
1
Request Service SCR
Cleaning
-
Recommend SCR Cleaning in 10hr
Need Engine Warm up
2
ON
Should Do SCR Cleaning in 5hr
Need Engine Warm up
3 Blink
Must Do SCR Cleaning Immediately
Need Engine Warm up
4
Progressing Passive
SCR Cleaning
Progressing Service
SCR Cleaning
ON Hot Exhaust Gas
5
Service SCR Cleaning
Preparation Lamp
ON Warming up for SCR Cleaning
6
Under Cleaning SCR ON
Cleaning SCR
DO NOT STOP ENGINE
7
SCR Cleaning Finish - ON SCR Cleaning completed
8
SCR Cleaning inhibit
switch ON
ON SCR Cleaning is inhibited
