G424F(FE) Service Manual Chapter 4. Engine Electrical System 101
Chapter 4. ENGINE ELECTRICAL SYSTEM
Specifications
Ignition Coil
Item Specification
Primary resistance 0.15Ω
Secondary Load resistance 2,500Ω
Spark Plug
Item Specification
Spark plug gap 0.7 ~ 0.8mm
Starter Motor
Item Specification
Output 12V- 1.4 kW
Pinion tooth number 8
Alternator
Item Specification
Rated output 13.5V - 80A
RPM 1,000 ~ 18,000rpm
Voltage regulator type Electronic, Built-in type
