G424F(FE) Service Manual Chapter 3. Engine Mechanical System 36
Recommended Torque Values
nuts N•m
Starter to cylinder block 45
Exhaust manifold to cylinder head 18-22 1)
Dipstick oil tube to cylinder block 20-30
DIS Ignition Module to camshaft housing carrier 8
Throttle body to intake manifold 11-13
Pressure plate to camshaft housing 8
Intake manifold to cylinder head 18-22 1)
Crankshaft position sensor 6
Rear toothed belt cover bolts 8
Rear toothed belt cover nuts 7
Heat shield to exhaust manifold 6-8
bolts N•m
V–belt tensioner to alternator support 25
Fuel distributor tube to intake manifold 22-30
Fuel supply and return line to throttle valve guards 15
Water pump to cylinder block 25
Coolant pipe to cylinder block 20
Crankshaft main bearing cap to cylinder block 50 N•m + 45° + 15°
Oxygen sensor to exhaust manifold 35-44
Crankcase oil baffle plate and bridge bolts 20
Camshaft housing cover to camshaft housing 8
Camshaft sprocket to camshaft 45
Oil drain bolt to oil pan 40-70
Oil pressure switch to oil pump 30-50
Oil filter to oil pump Hand Tight
Oil pump to cylinder block 10
Oil pump cover to oil pump 6
Oil intake pipe to oil pump 10
Oil intake pipe to cylinder block 8
Oil baffle plate to oil pan 8
Oil pan to transmission 40
