G424F(FE) Service Manual Chapter 6. LPG FUEL DELIVERY SYSTEM 189
Parts Description
CA100 Mixer for G424FE Engine
Parts List of CA100 Mixer (Certified)
REF NO DESCRIPTION QTY
1 Torx Screws (T-25) #10-24 x 5/8” 4
2 Lockwashers (T-210) #10 SST 4
3 Mixer Cover 1
4 Mixer Spring 1
5 Diaphragm 1
6 Air Valve Assembly 1
7 Gas Valve Cone (part of air valve assembly) 1
8 Mixer Body 1
9 Expansion Plug Cap Ø 1/2” x 1/16” thick (Ø 12.7mm x 27mm) 1
10 Fuel Inlet 1
11 Air Horn Gasket 1
12 Air Horn Adapter 2-1/16” (52.37mm) 1
13 Fillister Head Screws SEMS Lockwasher 10-24 UNC x 5/8” 4
14 Throttle Body Gasket 1
15 Fillister Head Screws SEMS Split Lockwasher #12-24 x 5/8” 4
