3. Motion Aperture (MA)
Option Description
3 Select 3 divisions of motion
1 Select 1 division of motion
5 Select 5 divisions of motion
Motion Aperture is used to select how many displayed divisions of motion must be sensed
between updates before the unit will go into a motion state.
4. Serial Data Output (d.o.)
Option Description
tod Transmit on Demand
Cnt Continuous Transmission
AP1 Auto Print 1
AP2 Auto Print 2
AP3 Auto Print 3
L.o.d. Latch on Demand (Transmit when Stable)
tP Timed Print, prints out data every 10 seconds
Atd Latch on Demand, acceptable weights only
AP4 Auto Print 4
APUO Same as AP3 but will only print when scale is in over or under.
For a detailed explanation of the Data Output Modes, see Section 8 on using the data
interface.
5. Startup Units (S.U.)
Option Description
Lb Startup in "lb"
Kg Startup in "kg"
OZ Startup in "oz"
L O Startup in "lb & oz"
g Startup in "g" (uses kg annunciator)
The Startup Unit is simply the weight display unit that the 4200 reads in when the scale is
turned on. Select the unit you will use exclusively or the unit most frequently used as your
startup unit.
Section 6 Parameter Setup
30
