Span Range Selection
(Active Live Load)
SW2
pos 8
SW2
pos 7
SW2
pos 6
0.50 - 1.25 mv/v 0 1 1
1.00 - 2.50 mv/v 0 0 1
2.00 - 3.50 mv/v 0 0 0
DIGITAL CALIBRATION
The digital calibration is necessary to match the raw span value to the actual displayed
weight. This is done using an accurate test weight.
In order to perform the digital calibration, you must have an accurate test weight equal to at
least 20% of your scale's capacity or 5% for capacities greater that 1000 lbs. The
following is a table of scale capacity vs. the minimum recommended amount of test weight
that should be used for digital calibration.
Scale Capacity Minimum Recommended Test Weight
for Span Calibration
6 lb 6 lb
15 lb 15 lb
30 lb 30 lb
60 lb 60 lb
100 lb 100 lb
120 lb 120 lb
150 lb 100 lb
200 lb 100 lb
300 lb 150 lb
600 lb 300 lb
1105 lb 500 lb
3000 lb 1500 lb
6000 lb 2000 lb
15000 lb 5000 lb
20000 lb 5000 lb
30000 lb 10000 lb
60000 lb 20000 lb
120000 lb 50000 lb
Section 7 Calibration
49
