12. Tare Entry Mode (tAr)
Option Description
SEt Tare entered via UP and DOWN arrow buttons.
P.t.t. Tare entered by single press of TARE button.
diS Tare entry disabled.
The Tare Entry Mode parameter allows the user to select how the tare parameter in the
4200 operates. It can be either a standard "Push to Tare" button, causing the weight
display to come to zero when pressed, or it can be used in conjunction with the UP and
DOWN arrow buttons to preset a tare value from the front panel. In addition, the tare button
can be disabled if it is not to be used, or if it is desired to preset a tare to secure it from
tampering by the scale operator. See Section 4 for more information.
13. Baud Rate Selection, Port 2 - Printer (b.r.t.)
Option Description
30 300 baud
120 1200 baud
240 2400 baud
480 4800 baud
960 9600 baud
19.2 19200 baud
The Baud Rate parameter is used to select the data output rate for the transmitting of serial
data through the simplex (printer) port.
13a. Baud Rate Selection, Port 1 - Duplex (d.b.r.)
Option Description
30 300 baud
120 1200 baud
240 2400 baud
480 4800 baud
960 9600 baud
19.2 19200 baud
To select the baud rate for the duplex port, press the PRINT button to enter the Duplex Port
Selection when the parameter menu is in Baud Rate Selection Simplex Port (b.r.t). If the
pass-through mode is used, both ports must have the same baud rates.
Section 6 Parameter Setup
37
