14. Data Bits and Parity, Port 2 - Printer (d.b.P)
Option Description
8n 8 data bits, no parity.
7 n 7 data bits, no parity.
7 O 7 data bits, odd parity.
7 E 7 data bits, even parity.
The Data Bits and Parity parameter is used to select the number of data bits for each
character transmitted through the simplex (printer) port. For error checking, a parity bit can
be selected for the device(s) that require it. Select the proper option for the peripheral
device(s) being used in the application.
14a. Data Bits and Parity, Port 1 - Duplex (d.b.1)
Option Description
8n 8 data bits, no parity.
7 n 7 data bits, no parity.
7 O 7 data bits, odd parity.
7 E 7 data bits, even parity.
The Data Bits and Parity for the Duplex port provide the same functionality as the Simplex
port. To access these options for the duplex port, press the PRINT button when the d.b.P
parameter is selected.
15. Print Format (PFt)
Option Description
1 Weight, net, and over/accept/under.
2 Scale i.d., Weight, net, over/accept/under.
3 Scale i.d., Product no., Weight, net, over/accept/under.
4 Product no., Weight, net, over/accept/under.
5 Weight, net, over/accept/under. Tare weight, keyed/not keyed.
6 Scale i.d., Weight, net, over/accept/under. Tare weight, keyed/not keyed.
7 Scale i.d., Product no., Weight, net, over/accept/under. Tare weight, keyed/not keyed.
8 Product no., Weight, net, over/accept/under. Tare weight, keyed/not keyed.
9 Output for a DGH analog output module.
10 Over/Accept/Under.
11 Weight, "grs/net" 8000 output emulation.
12 Output for A&D Printers.
13 Label Buffer output format. See Section 8.
14 Dual Print - same as format 1, plus prints kg weight. See Section 8.
15 Dual Print - same as format 4, plus prints kg weight. See Section 8.
Section 6 Parameter Setup
