Doran 4200 - Page 59

Span switch settings - PCB035 Rev. 2.0 (no zero pot)
Load Cell Output S3-1 S3-2 S3-3 S3-4
0.5 mv/v 1 1 1 1
0.75 mv/v 1 1 0 1
1.0 mv/v 1 0 0 1
1.5 mv/v 0 1 1 0
2.0 mv/v 0 0 0 1
2.5 mv/v 0 0 0 0
Zero Offset switch settings - PCB035 Rev. 2.0 (with zero pot)
Zero Offset S2-1 S2-2
60% zero up or down adjustment 0 0
40% to 160% zero down adjustment 1 0
115% to 235% zero down adjustment 0 1
215% to 335% zero down adjustment 1 1
Span switch settings - PCB035 Rev. 2.0 (with zero pot)
Load Cell Output S3-1 S3-2 S3-3 S3-4
0.5 mv/v n/a 1 1 1
1.0 mv/v n/a 1 1 0
1.5 mv/v n/a 1 0 1
2.0 mv/v n/a 0 1 0
2.5 mv/v n/a 0 0 1
3.0 mv/v n/a 0 0 0
