DOTECH UIC-DX270 - Basic Features

UIC-DX270 Series User’s Manual Rev 1.0
- 10 -
2) BASIC FEATURES
2-1) General feature
Power Conditions
Input power AC24V 50/60Hz, DC24V
Output power 20VA(Maximum)
2-2) CPU and LCD
CPU, LCD
C P U ATmega 128, 16MHz
L C D 240 X 128 pixel, LED Backlight
2-3) Digital input/output
Digital Input
Input Method Opto-Isolation
Number of Input 10 (5 X 2 Common)
Signal Power AC24V or DC24V
Digital Output
Output Method Relay contact
Number of Output 12, (4 X 3 Common)
Relay Contact 250V, 10A (NAIS JQ1P Series)
2-4) Analog input/output
Analog Input
Temperature Sensor NTC 3
0~1VDC, 4~20Madc 2 (sensor power 24V )
Declination Revision Software
Analog Output
Number of Channel 3 channel
Output Method 4~20mA
Setting Form software
2-5) Communication feature
Communication
Communication Method RS485(half-duplex), 2 Channel
Communication Speed
4800, 9600, 19200, 38400 BPS
Parity None, Data 8bit, Stop 1bit
Communication Distance 1.2Km (maximum)
Suggested Cable BELDEN 9841(2) or 8761
2-6) Installation features
Field Conditions
Install Place Indoor
Operation Temperature -10 ~ 60 ℃
Storage Temperature -30 ~ 80 ℃
Operation Humidity Non-humidity 5~95%
