4) ANALOG OUTPUT SIGNAL (OPTIONAL FUNCTION)
Pin Name Function Type
J6.1 Y1 Entrance Temp. Signal (+)
4 ~ 20mA
J6.2 YG1 Entrance Temp. Signal (-)
J6.3 Y2 Exit Temp. Signal (+)
4 ~ 20mA
J6.4 YG2 Exit Temp. Signal (-)
J6.5 Y3 Discharge Gas Temp. Signal (+)
4 ~ 20mA
J6.6 YG3 Discharge Gas Temp. Signal (-)
* Entrance Temperature Signal Range: 4 ~ 20mA (-30.0 ~ 70.0 ℃)
* Exit Temperature Signal Range: 4 ~ 20mA (-30.0 ~ 70.0 ℃)
* Discharge Gas Temperature Signal Range: 4 ~ 20mA (0.0 ~ 200.0 ℃)


