DOTECH UIC-DX270 - Advanced Operating and System Settings

UIC-DX270 Series User’s Manual Rev 1.0
- 32 -
9) EXTENT OPERATING SET
Item Description Units Step Min Max Default View Access
500 Running mode -
LOCAL / REMOTE CONTROL /
RESERVATION
LOCAL SVC1 SVC1
502 Control source - IN / OUT / B4 / E-B4 / P-B4 OUT SVC1 SVC2
503 Step delay time Sec. 1 0 999 10 SVC1 SVC2
504 Step delay time(start) Sec. 1 0 999 180 SVC1 SVC2
507 Comp. start delay time Sec. 1 0 600 5 SVC1 SVC2
508 Comp. restart delay time Min. 1 0 30 5 SVC1 SVC2
509 Comp. auto stop delay Sec. 1 0 600 5 SVC1 SVC2
510 Comp. stop delay Sec. 1 0 600 5 SVC1 SVC2
511 Start sol off delay Sec. 1 0 600 30 SVC1 SVC2
512 Pump(fan) off delay Min. 1 0 30 0 SVC1 SVC2
513 Y/D,P/W change time Sec. 0.1 0.1 30.0 5.0 SVC1 SVC2
514 Pump-down set Sec. 1 0 600 0 SVC1 SVC2
515 Blackout return func. - OFF / ON ON SVC1 SVC2
516 System address setting
**
- 1 1 128 1 SVC1 SVC2
517 Local address setting
**
- 1 1 128 1 SVC1 SVC2
518 System communication speed
**
-
4800, 9600, 19200, 38400
9600 USER2 USER2
519 Local communication speed
**
- 9600 USER2 USER2
**
The function that can communicate with was installed, and be marked.
1) Running mode: local(Use keypad of a controller), remote control(Use digital input ID10),
reservation (Use schedule operation)
2) Control source : control source setting (IN: entrance temperature, OUT: exit temperature, B4:
outdoor temperature , E-B4: outdoor capacity, P-B4: low pressure control) B4, E-B4, P-B4 is
4~20mA input style
3) Comp. start delay time: ON does liquid stream valve and operation valve, and a compressor sets
up time of operation
4) Comp restart delay time: Compressor set up after OFF, and it is possible a driving compressor
since time was passed
5) Comp. auto stop delay: A compressor sets up the time that is condition that is OFF, delay time (By
temperature)
6) Comp. stop delay: The time that is condition that a compressor is OFF, delay time (By keypad,
digital input ID10 etc)
7) Start sol off delay: ON sets later up time to operating-valve a compressor until select OFF
8) Pump(fan) off delay: Set up circulation driving time of pump(fan)
9) Pump-down set: Set the pump-down time of freezer
10) Blackout return func.:After a stoppage of power supply, set return or not previous Operation/stop
