2) MENU STRUCTURE
00: INLET TEMP
01: OUTLET TEMP
02: DISCHARGE GAS
03: RUN HOUR
04: COMPS RUN HOUR
05: COMPS ON/OFF
OPERATION
00: SET VALUE
01: RUN DIFFERENTIAL
02: STOP DIFFERENTIAL
03: 50%CAP.DIFFERENTIAL
04: 75%CAP.DIFFERENTIAL
05: ○
+
D.BAND DIFFERENTIAL
06: ○
-
D.BAND DIFFERENTIAL
07: INJECTION SET VALUE
08: INJECTION DIFFERENTIAL
09: LCD BACKLIGHT MODE
SCHEDULE
00:SUN : ON ~ OFF
01:MON : ON ~ OFF
02:TUE : ON ~ OFF
03:WED : ON ~ OFF
04:THU : ON ~ OFF
05:FRI : ON ~ OFF
06:SAT : ON ~ OFF
TRIP LOG
EVENT #1
EVENT #2
EVENT #3
|
EVENT #160
TRIP AND ALARM
00: FLOW SENSING DELAY
01: FLOW SENSING HOLD
02: DISCHARGE TEMP. OVER
03: OUTLET TEMP FREEZE
04: OIL FLOW SENSING DELAY
05: OIL FLOW SENSING HOLD
06: LOW PRESS SENSING DELAY
07: LOW PRESS SENSING HOLD
08: OIL LEVEL SENSING DELAY
09: OIL LEVEL SENSING HOLD
10: CONDENSOR FAULT FUNC.
EXTENTION
00: RUNNING MODE
01: CONTROL SOURCE
02: STEP DELAY TIME
03: STEP DELAY TIME (STRAT)
04: COMP. STRAT DELAY TIME
05: COMP. AUTO STOP DELAY
06: COMP. STOP DELAY TIME
07: START SOL OFF DELAY
08: PUMP(FAN) OFF DELAY
09: Y/D,P/W CHANGE TIME
10: PUMP-DOWN DELAY TIME
11: BLACKOUT RETURN FUNC.
CALIBRAITION
00: INLET TEMP SENSOR CAL.
01: OUTLET TEMP SENSOR CAL
02: DISCHARGE SENSOR CAL
TEST MODE
00: MANUAL TEST MODE
01: CR1 CAPACITY SOL
02: CR2 CAPACITY SOL
03: CR3 CAPACITY SOL
04: MAIN LIQUD SOL
05: COMPS MM•PW1
06: COMPS MY•PW2
07: COMPS MD
08: INJECTION SOL
09: SPARE
10: RUN STATE
11: TOTAL ALARM
12: PUMP(FAN) CONTROL
FACTORY SET
00: SELF TEST
01: LOG CLEAR
02: INFO CLEAR
03: B1 INPUT
04: B2 INPUT
05: B3 INPUT
06: B4 INPUT
07: B5 INPUT
08: B4 4mA SET
09: B4 20mA SET
10: B5 4mA SET
11: B5 20mA SET
12: Y1 4mA SET
13: Y1 20mA SET
14: Y2 4mA SET
15: Y2 20mA SET
16: Y3 4mA SET
17: Y4 20mASET
18: ADC FILTER
19: DAC FILTER
CONFIGURE
00: COMP START METHOD
01: INLET TEMP SENSOR
02: OUTLET TEMP SENSOR
03: DISCHARGE TEMP SENSOR
04: INJECTION SOL TYPE
05: START CAPCITY METHOD
06: 50% CAPCITY METHOD
07: 75% CAPCITY METHOD
08: 100% CAPCITY METHOD
RUN INFO
