UIC-DX270 Series User’s Manual Rev 1.0
- 36 -
13) FACTORY SET
※ This is the set mode when delivered thus, please understand exactly and then, changes it .
Item Description Units Step Min Max Default View Access
900
Self test
NO / YES NO SVC2 SVC3
901
Log clear
NO / YES NO SVC2 SVC3
902
Info clear
NO / YES NO SVC2 SVC3
903
B1 Input
Only View
997 SVC2 -
904
B2 Input
280 SVC2 -
905
B3 Input
997 SVC2 -
906
B4 Input
280 SVC2 -
907
B5 Input
997 SVC2 -
908
B4 4mA set
1 0 1023
280 SVC2 SVC3
909
B4 20mA set
997 SVC2 SVC3
910
B5 4mA set
280 SVC2 SVC3
911
B5 20mA set
997 SVC2 SVC3
912
Y1 4mA set
1 0 9999
810 SVC2 SVC3
913
Y1 20mA set
3510 SVC2 SVC3
914
Y2 4mA set
810 SVC2 SVC3
915
Y2 20mA set
3510 SVC2 SVC3
916
Y3 4mA set
810 SVC2 SVC3
917
Y4 20mA set
3510 SVC2 SVC3
918
ADC filter
1 1 256 8 SVC2 SVC3
919
DAC filter
1 1 256 8 SVC2 SVC3
This product has a digital control function in terms of a digital Input/Output function.
When customer wants the change something, please contact to [DOTECH] company.
1) Self test: It is set ‘ON’, when taking test or delivered.
2) Log clear: Use to delete Trip Warning Background.
3) Info clear: Use to delete Operation Background.
4) Bn 4mA: Analog Input(4mA)
5) Bn 20mA: Analog Input (20mA)
6) Yn 4mA: A constant of change Analog signal (4mA)
7) Yn 20mA: A constant of change Analog signal (20mA)

