DOTECH UIC-DX270 - Trip and Alarm Management Functions

UIC-DX270 Series User’s Manual Rev 1.0
- 29 -
The state of equipment during trip


8) TRIP AND ALARM
Item Description Units Step Min Max Default View Access
400 Flow sensing delay
Sec. 1 0 300 60 SVC1 SVC1
401 Flow sensing hold
Sec. 1 0 300 5 SVC1 SVC1
402 Discharge temp over ℃ 1 50 180 115 SVC1 SVC1
403 Outlet temp freeze
℃ 1 -99 99 3 SVC1 SVC1
404 Oil flow sensing delay
Sec. 1 0 300 60 SVC1 SVC1
405 Oil flow sensing hold Sec. 1 0 300 0 SVC1 SVC1
406 Lo press sensing delay
Sec. 1 0 300 60 SVC1 SVC1
407 Lo press sensing hold
Sec. 1 0 300 5 SVC1 SVC1
408 Oil level sensing delay Sec. 1 0 300 60 SVC1 SVC1
409 Oil level sensing hold
Sec. 1 0 300 5 SVC1 SVC1
410 Condensor fault func.
Off / On On SVC1 SVC1
1) Flow state error fault
 Stream detection delay time: Start for perceiving after delay time since a pump(fan) was
operated a detection of a stream detection switch. (Be always detections if set up in 0
seconds.)
