DOTECH UIC-DX270 - Trip Log

UIC-DX270 Series User’s Manual Rev 1.0
- 28 -
7) TRIP LOG
Item Date Time Occur/Reset Event
1 Y Y / M M / D D H H : M M ( X ) The name of Trip warning #1
2 Y Y / M M / D D H H : M M ( X ) The name of Trip warning #2
3 Y Y / M M / D D H H : M M ( X ) The name of Trip warning #3
4 Y Y / M M / D D H H : M M ( X ) The name of Trip warning #4
5 Y Y / M M / D D H H : M M ( X ) The name of Trip warning #5
|
|
|
|
|
|
|
|
|
|
160 Y Y / M M / D D H H : M M ( X ) The name of Trip warning #160
※ It is not possible to modify or erase log.
① If Trip Warning occurs (cancel), event date and the name of trip warning is saved in
nonvolatile memory.
② Maximum is 160, it is deleted and saved previous events over 160 events.
③ When occurring, date, time, event (trip warning) are recorded, when canceling, ‘X’ is showed
next to time.
④ If putting [Enter], Operation state Code, Exit Pressure, Exit Temp., and Surrounding Temp. Are
showed.
⑤
