11) CALIBRATION
Item Description Units Step Min Max Default View Access
700
Inlet temp sensor cal
℃ 1 -20.0 +20.0 0.0 USER 2 USER 2
701
Outlet temp sensor cal
℃ 1 -20.0 +20.0 0.0 USER 2 USER 2
702
Discharge-gas temp cal
℃ 1 -20.0 +20.0 0.0 USER 2 USER 2
703
Press sensor cal
Bar 1 -20.0 +20.0 0.0 USER 2 USER 2
704
Press sensor range lo
Bar 1 -1 +100 0 USER 2 USER 2
705
Press sensor range hi
Bar 1 -1 +100 30 USER 2 USER 2
706
Exit temp sensor cal
℃ 1 -20.0 +20.0 0.0 USER 2 USER 2
707
Exit temp sensor lo
℃ 1 -50 +200 -20 USER 2 USER 2
708
Exit temp sensor hi
℃ 1 -50 +200 80 USER 2 USER 2
1) Inlet temp sensor cal: Input a revision price of an entrance temperature sensor.
2) Outlet temp sensor cal: Input a revision price of an exit temperature sensor.
3) Discharge-gas temp cal: Input a revision price of a discharge-gas temperature sensor.
4) Press sensor range lo: Input an inferior limit price of a pressure sensor.
5) Press sensor hi: Input an upper limit price of a pressure sensor.
