UIC-DX270 Series User’s Manual Rev 1.0
- 30 -
Stream detection operation time: Shall be OFF state during action time, and input of a stream
detection switch perceives.( If it is 0 seconds, do not perceive)
2) Outlet temp freeze: A trip function runs hereafter the freezing temperature that exit temperature is
excessive.
3) Oil flow error fault
Oil flow delay: Start for perceiving after delay time since a freezer was driven a detection of
an oil stream switch. (( Be always detections if set up in 0 seconds)
Oil flow operation time: Shall be OFF state during action time, and input of an oil stream
switch perceives. (If it is 0 seconds, do not perceive)
4) Lo press error fault
Lo press sensing delay: Start for perceiving after delay time since a freezer was driven a
detection of a low pressure switch. (Be always detections if we set up in 0 seconds)
Lo press sensing time: Shall be OFF state during action time, and input of a low pressure
switch perceives (If it is 0 seconds, do not perceive)
5) Oil level error fault
Oil level delay time: Start for perceiving after delay time since a freezer was driven a
detection of an oil level switch.( Be always detections if we set up in 0 seconds)
Oil level operation time: Shall be OFF state during action time, and input of an oil level switch
perceives. (If it is 0 seconds, do not perceive)
6) Condensor fault func.: If it is an air cooling formula, select whether or not there is by condensor
Fan alarm use.
8-1)
Trip alarm message
Item Description Detect condition
1
Outlet sens. flt.
Detection If an error occurred to an exit direction temperature sensor (Breaking of wire)
Cancellation If an exit direction temperature sensor is normal
2
Dc gas sens. flt.
DetectionIf an error occurred to an exit direction discharge-gas sensor (Breaking of wire)
Cancellation If an exit direction discharge-gas sensor is normal
3
Pump(fan) fault
Detection [Digital signal input:ID9:pump(fan)interlock] signal OFF
Cancellation [Digital signal input:ID9: pump(fan)interlock] signal ON
4
Flow fualt
Detection [Digital signal input:ID8:flow] signal OFF
Cancellation [Digital signal input:ID8:flow] signal ON
5
Comp ocr
Detection[Digital signal input:ID1: Be detections to over-current of a freezer] signal OFF
Cancellation[Digital signal input:ID1: Be detections to over-current of a freezer] signal ON
6
Phase fault
Detection [Digital signal input:ID2: Be detections to back current of a freezer] signal OFF
Cancellation[Digital signal input:ID2: Be detections to back current of a freezer] signal ON
7
Low press fault
Detection[Digital signal input:ID3: A low pressure switch of a freezer] signal OFF
Cancellation[Digital signal input:ID3: A low pressure switch of a freezer] signal ON
8
Hi press fault
Detection [Digital signal input:ID3: A high pressure switch of a freezer] signal OFF
Cancellation[Digital signal input:ID3: A high pressure switch of a freezer] signal ON
