UIC-DX270 Series User’s Manual Rev 1.0
- 20 -
ON: LED is on always, OFF: LED is not on always.
Low speed flickering: ON for 0.5sec, OFF for 0.5sec
High speed flickering: ON for 0.1sec, OFF for 0.1sec
Spot flickering: ON for 0.1sec, OFF for 4sec
State
No.
State
Operation State Lamp
Alarm State Lamp
0 Initialization OFF
Normal: OFF
Trip: High speed
flickering
Alarm: Low speed
flickering
1 Inhibit check OFF
2 Start ready OFF
3 Timer Value Initialization OFF
4 Pump (fan) start delay High speed flickering
5 Pump(fan) start High speed flickering
6 Waiting operation High speed flickering
7
Capacity control value
Initialization
High speed flickering
8 Comp. Operation Delay High speed flickering
9 Comp. Start High speed flickering
10 Start sol off Delay ON
30 Comp. Manual Stop Delay Low speed flickering
31 Pump Down Delay Spot flickering
32 Restart Delay
Low speed flickering /
Spot flickering
40 Pump(Fan)off Delay Spot flickering
41 Pump(Fan) off
Low speed flickering /
Spot flickering
50 Capacity Maintenance Operation ON
51 Capacity Decrease Operation ON
52 Capacity Increase Operation ON
53 Comp. Auto Stop Delay Low speed flickering
99 Shut-Down OFF
