58 16.50 PRO DR
®
RAPID-FEED™ CHIPPER
nd
9. Pull the excess wire to the front of the Chipper.
11. Hitch Bolt, wrap the White (Ground )
Wire around the Bolt, and then re-tighten with two
12. Roll up the extra wire and wire tie it to the Tow Bar.
NOTE: We recommend that you wrap the Harness Wires together
with e ire
Harness Connector end and going back to where the wires go to
either side of the Frame.
7. Attach both Light Brackets to the Frame with Bolts a
Locknuts with two 1/2" wrenches (Figure 66).
Light
Bracket
Figure 66
Bolt and
Locknut
8. Secure the Wires under the Frame with Cable Ties at
the four places shown (Figure 67).
Wire Harness
Figure 67
Cable
Ties
Ground
Wire
Figure 68
Cab
Excess
to Tow B
le Tie
Wire
ar
Trailer
Hitch Bolt
10. Strip 1" of insulation from the end of the White
(Ground) Wire.
Loosen a Trailer
3/4" wrenches (Figure 68).
lectrical tape about every twelve inches starting at the W
