Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n 201
Configuration
10.7 Intelligent alarm behavior
10.7.1 Combined alarms
If multiple alarms occurring at the same time are caused by the same problem, they
are combined into one alarm.
10.7.2 Limited generation of alarms
Some low-priority alarms indicate a fault in a measurement function. If this
measurement function monitors parameters, no alarms based on these parameters
can be generated.
Example:
11 Configuration
11.1 Safety instructions
Unauthorized configuration changes
If the device configuration has been changed without authorization, settings may be
incorrect. As a result, device malfunctions can occur and the patient may be put at
risk.
► Restore the device configuration.
Passwords
If the user password and the service password are not assigned, there is a risk of
unauthorized access to the device settings. As a result, saved device settings can
be changed and not be noticed. The patient may be put at risk. Skip password
assignment only in emergencies.
► Assign the user password and the service password when the device is
switched on for the first time.
11.2 User password
To prevent unauthorized changes, the start settings for this device are protected by
a password. After a specified interval, a new password must be assigned. This
interval can be configured in the service dialog. If the password needs to be reset,
contact service personnel.
Give the password only to authorized persons.
Problem Alarms occurring at the
same time
Combined alarm
Several causes of apnea
are present.
Apnea (no flow)
Apnea (no pressure)
Apnea (no CO
2)
Apnea
Fault Displayed alarm Non-generated alarm
CO
2 measurement is
faulty
Sample line occluded Apnea (no CO2)
