Dräger Atlan A100 - Available Test Types

Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n 111
Tests
7.3 Available test types
System test A100
(XL)
A300
(XL)
A350
(XL)
Type and dura-
tion:
Automatic, approx. 8 min
Perform the test: Daily
Description: Scope of the pretest (initialization):
– Checking situations that frequently cause operational
restrictions:
– Insufficient O
2 gas supply
– No gas cylinders connected
– High leakage
– Condensed water in the breathing system, in the
piston diaphragm, and in the breathing circuit
– Insufficient power supply, including the internal
battery
– Mix-up of the connected breathing hoses
●●●
– Incorrectly set APL valve
– Missing valves in the breathing system
– Insufficient pressures of N
2O and Air
--- ●●
– Calibrating the inspiratory O
2 sensor ●●●
The initialization takes approximately 2 to 3 minutes. Remain by the device during
this time. Make corrections if necessary.
Scope of the fully automatic main test:
– Checking the functional integrity:
– Does the connected O
2 supply actually supply
oxygen?
1)
1) Only for devices with integrated PGM. This test must be activated in the system setup (see "Vertical tab "System
test"", page 219).
--- ●●
–Gas mixer --- ●●
– Breathing system ●●●
– Patient gas measurement
– Alarm system and the associated loudspeakers
– Breathing system warmer
– Detection of an excessively high suction flow at the
AGS
– Performance of leakage test
– Calibrating sensors and valves
– Flushing the breathing system with ambient air
●●●
