178 Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n
Operation
2. Touch the System > Sound volume tab (1).
3. For Alarm volume, set the desired value (2).
8.10 Adjusting the alarms
8.10.1 Setting the alarm limits
For a current case, the alarm limits can be set in 2 ways:
– Setting using the Quick setup dialog
– Setting using the Alarms dialog
Setting using the Quick setup dialog
1. Touch the respective waveform or the parameter field.
2. Set the upper alarm limit (1).
3. Set the lower alarm limit (2).
35918
2
1
1
System setup
35922
1
2
Quick setup
