76 Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n
Assembly and preparation
4.5 Gas supply
4.5.1 Connecting to the central gas supply system
1. Screw the compressed gas hoses for the central gas supply system to the gas
inlets by hand, see page 31.
WARNING
Danger to the patient and user
If the strain relief for the compressed gas hoses is not used, the device may be
damaged.
Use the strain relief for the compressed gas hoses.
2. Insert the compressed gas hoses into the strain relief. Tighten the strain relief,
see page 28.
3. Connect the compressed gas hoses to the terminal units.
4. Check that all hoses are correctly connected and that the gas supply is
established. To do this, observe the corresponding displays on the gas mixer
unit, depending on gas mixer:
Symbols on the status display
Integrated pressure gauges
For further information see: "Gas mixing unit", page 34.
4.5.2 Connecting the gas cylinders
4.5.2.1 Connecting gas cylinders with screw connections
WARNING
Danger to the patient and user
If the strain relief for the compressed gas hoses is not used, the device may be
damaged.
Use the strain relief for the compressed gas hoses.
WARNING
Risk of fire
Ignition sources together with oxygen can cause fires.
Do not position oxygen sources in the vicinity of ignition sources, e.g., electrical
connectors.
Always fit the oxygen cylinder in the right-hand fixing position on the rear.
