Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n 265
Troubleshooting
!!! 100 System failure The gas delivery and the
controlled ventilation have
failed due to an internal fault.
Proceed as follows: -Activate
the backup manual mode,
then ventilate the patient with
the breathing bag. Or -Dis-
connect the patient, then use
a manual resuscitator.
Call Dräger.
!!! 0 Therapy settings not
applied
The last changes to the ther-
apy settings were not
applied.
Change to Man/Spon mode,
then switch back to the
desired ventilation mode.
Use "ALARM RESET" to
reset alarm.
If the problem persists, call
Dräger.
!! 100 Third agent detected A mixture of more than 2
anesthetic agents has been
detected.
Flush the system if neces-
sary.
Check fresh-gas settings.
Wait for transition phase to
end.
There is electromagnetic
interference.
Check for electromagnetic
radiation in the vicinity.
!! 90 Tidal volume not achieved The delivered inspiratory
tidal volume is lower than the
set value.
Check ventilation settings.
Check Pmax setting.
Check patient compliance.
Check if the patient is breath-
ing spontaneously.
! 0 USB write error The USB flash drive is full,
faulty, write-protected, or not
compatible. The USB flash
drive is not correctly con-
nected. The USB flash drive
is not correctly formatted.
Check the USB flash drive.
Use "ALARM RESET" to
reset alarm.
!!! 120 Ventilator failure The piston ventilator or at
least one pressure sensor is
faulty.
Start manual ventilation!
When the case has been
completed, perform a sys-
tem test.
If the problem persists, call
Dräger.
Use "ALARM RESET" to
downgrade alarm priority.
! 160 Volume inaccurate (ambi-
ent pressure implausible)
The ambient pressure mea-
surement is implausible. Vol-
ume monitoring and volume
delivery may be inaccurate.
Check the setting for "Height
above sea level" in the sys-
tem setup.
Perform the system test.
If the problem persists, call
Dräger.
! 100 Water trap disconnected? Infinity ID water trap is not
correctly connected.
Check water trap.
Priority Alarm Cause Remedy
