32 Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n
Overview
3.1.10 Hanger yokes with pin-index connection
36476
No. Designation Description
1 Protection bar Protects the connectors for the gas cylin-
ders from damage.
2 Hanger yoke system with three
pin-index connectors
Enables the connection of gas cylinders
with a pin-index connector.
3 Wrench For opening and closing the gas cylinder
valves.
4 Connecting cable Enables electronic gas pressure measure-
ment.
