42 Instructions for use | Atlan A100 (XL), A300 (XL), A350 (XL) SW 2.1n
Overview
External fresh-gas outlet – Allows use with external non-rebreathing systems,
e.g.:
– Mapleson
–Kuhn
–Bain
– Magill
–Waters
Gas cylinder connectors Enable the device to be supplied with gases from the
gas cylinders.
Hanger yoke system Enables the connection of gas cylinders with a pin-
index connector.
Gas cylinder holder Used to fix the gas cylinders.
Gas cylinder park holder Can hold an additional gas cylinder.
Advanced Cylinder Sup-
port
On devices that are equipped with Advanced Cylinder
Support, the gas cylinder valves can also remain open
during operation with the central supply.
Support of Infinity ID
accessories
Allows the use of Dräger Infinity ID accessories with
the following functions:
– Generates a message when the maximum period
of use is exceeded for the breathing circuit, the
water trap, the CO
2 absorber, and the flow sensors
– Generates a message when the breathing circuit is
incorrectly connected
– Generates a message when the CO
2 absorber is
not present or is not locked
Breathing bag arm Used to attach the breathing bag to the breathing sys-
tem.
Airway pressure gauge Mechanically measures the airway pressure and dis-
plays it on an analog indicator.
Total flow tube Indicates the total fresh-gas flow.
Holder for hoses and
cables
Used for storing and winding up central supply hoses
and cables on the rear of the device.
Cable holder with cable
channels
Used for routing hoses and cables on the rear of the
device.
Side folding table exten-
sion
Used to extend the work surface.
Pull-out writing tray Used to extend the work surface.
Pressure measuring lines
for gas cylinders
– Display of gas cylinder pressure
– On correspondingly equipped devices, an alarm is
issued when gas cylinders are empty.
Auxiliary power sockets Allow other devices to be connected.
Workplace light Used for additional illumination of the work surface.
Name Description
