Dräger EVITA XL

20 Pocket Guide Evita XL
Operation
Overview of the availability of additional
settings
Bronchial suctioning
Before suctioning
1 Touch Special Procedure ... button in the main
menu bar.
The Additional Function page (A) appears by default.
2 Touch O2
↑ suction button (B).
3 Press rotary knob to confirm.
The oxygenation procedure is started.
Evita XL ventilates the patient in the set ventilation
mode with the appropriately increased O
2 concentrati-
on.
The preoxygenation phase with the remaining time in
seconds is displayed continuously in the header bar.
Preoxygenation lasts for a maximum of 180 seconds.
During this time, Evita XL waits for the disconnection
necessary for suctioning. If no disconnection is detected
within 180 seconds, Evita XL terminates the oxygenati-
on procedure.
During suctioning
The time available for suctioning is displayed in se-
conds in the header bar. If suctioning is completed and
the patient reconnected within the time available,
Evita XL will end the disconnection phase.
After suctioning
After reconnection, Evita XL resumes ventilation in the
set ventilation mode. For postoxygenation, the O
2 con-
centration is increased for the first 120 seconds.
The postoxygenation phase with the remaining time in
seconds is displayed in the header bar.
Canceling oxygenation
Touch O2 ↑ suction button.
Ventilation
mode
Additional settings
ATC
(optional)
Apnea venti-
lation
Flowtrigger Inspiratory
termination
AutoFlow Sigh PLV
CMV X X X X X
SIMV X X X X X X
MMV X X X X X
ILV
Master XX XX
ILVSlave XXX
PCV+ X X X X
PCV+ Assist X X
APRV X X
CPAP/ PSupp X X X X
PPS (optional) X X X
026
A
B
