Dräger Oxylog 3000 plus - Displaying Curves; Displaying Measured Values

Monitoring
90 Instructions for use Oxylog 3000 plus SW 1.n
Displaying curves
The curve window can display the airway pressure
curve Paw, the flow curve or the CO
2 curve
(optional). Refer to "Screen structure" on page 32.
To display a different curve:
 Press the Curves key.
Displaying measured values
Measured values are displayed in the measured
values window.
To switch between the values:
 Press the Values key: the next value pair
is displayed on the screen.
The following values can be displayed:
–MVe
–FiO2
–f
–VTe
– PEEP
– Pmean
–PIP
–Pplat
– MVespon
– RRspon
–etCO
2
When the CO2 sensor is connected to the
ventilator, the etCO
2 value will be shown
automatically in the measured values window.
The values are shown in pairs; the pairs of values
can be configured as required. Refer to "Customer
Service Mode" on page 97.
Curves
