34 Instructions for use | Dräger PointGard 2000 Series
en | Accessories and spare parts
For connections to a wall outlet, only Dräger power supply
cables must be used. For fixed installations the power supply
cables must comply with the specifications in 17.3 Power
supply.
18.1.4 Mounting screws
To mount the instrument all screws with inner drive and the
following properties can be used.
18.2 PointGard 2100 EC
18.2.1 PointGard 2100 EC Accessories
18.3 PointGard 2200 CAT
18.3.1 PointGard 2200 CAT Accessories
18.3.2 Sensors
18.3.3 Sensors
18.4 PointGard 27x0 IR
18.4.1 Sensors
Check firmware compatibility of sensor and transmitter.
Changing the sensor may require a firmware update. For
support, contact Dräger.
Head diameter max. 11.5 mm / max. 0.45 In
Major diameter of the thread 6 mm / 0.2 In
Part Part number
EC Sensing Head Remote
mount kit
6812684
Remote Cable + Plug (5m) 8323305
Remote Cable + Plug (15m) 8323315
Remote Cable + Plug (30m) 8323330
Sensor Diagnostics Dongle 8317860
Sensor Test Dongle 8317619
Part Part number
Junction Box Aluminum
(Ex d explosion proof)
4544099
Junction Box Stainless Steel
(Ex d explosion proof)
4544098
DrägerSensor PR NPT DQ 6814150
Polytron
®
SE Ex PR M1 DQ
small standard housing
(includes sensor)
(Ex e enhanced safety)
6812711
Process adapter DQ M30 x
1,4
6812470
Description Part number
DrägerSensor DQ NPT 6814150
DrägerSensor LC NPT 6810675
Sensing head, Polytron SE
Ex PR M1 DQ
6812711
Sensing head, Polytron SE
Ex PR M2 DQ
6812710
Sensing head, Polytron SE
Ex HT M DQ
6812720
Description Part number
DrägerSensor IR NPT 6811901
Sensing head, DrägerSensor
IR
complete set e
6811165
Sensing head, DrägerSensor
IR
complete set e2
6811265
Description Part number
Dräger PIR 7000 Type 334
(NPT)
6811822
Dräger PIR 7000 Type 340
(NPT)
6811832
Dräger PIR 7000 334 (M25)
complete set
6811825
Dräger PIR 7000 340 (M25)
complete set
6811819
Dräger PIR 7200 (NPT) 6811572
Dräger PIR 7200 (M25)
HART, complete set
6812290
