Dräger PointGard 2000 Series User Manual

Accessories and spare parts | en
Instructions for use | Dräger PointGard 2000 Series 33
17.9.2 Sensor range electrochemical (EC)
sensors
18 Accessories and spare parts
For further information and configurations, consult the
technical manual 9300148.
This chapter is a non-exhaustive overview of the spare parts
that can be replaced performing the tasks described in this
IFU. For other parts refer to the spare parts list or contact
DrägerService.
18.1 PointGard 2xx0 Series
18.1.1 PointGard 2xx0 Accessories
18.1.2 Spare parts
18.1.3 Power supply cables
Sensor
Part-
number
Range
Default
value% LEL
Min. Defau
lt
Max. A1 A2
PR
DD/DQ
68 12
380
0 100 100 20 40
Sensor Part number
Range
Default
value
Min. Defa
ult
Max.
A1 A2
CO 6809605 50 300 1000 30 100
CO LH 6812570 50 300 300 30 100
CO LS 6809620 200 1000 5000 200 400
H
2S LC 6809610 10 50 100 10 20
H
2S 6810435 5 50 100 10 20
H
2S HC 6809710 100 500 1000 100 200
OV1 6810740 20 50 200 10 20
OV2 6810745 20 50 100 10 20
NO 6809625 30 50 200 10 20
O
2 LS 6809630 5 25 25 19 23
O
2 6809720 5 25 100 19 23
Hydride 6809635 0.3 1 20 0.1 0.2
Hydride
SC
6809980 0.3 1 1 0.1 0.2
HCN 6809650 10 50 50 10 20
HCN LC 6813200 5 50 50 4 8
NO
2 6809655 5 10 100 2 4
NO
2 LC 6813205 1 5 20 0.5 1
SO
2 6809660 5 10 100 2 4
CI2 6809665 1 10 50 0.5 1
H
2O2
LC
6809705 1 5 300 1 2
H
2O2
HC
6809675 1000 4000 7000 200 2800
H2 6809685 500 1000 3000 200 400
COCI2 6809930 0.1 1 20 0.1 0.2
Hydra-
zin
6810180 0.3 1 5 0.1 0.2
HCI SC 6809640 20 30 100 5 10
AC 6810595 3 10 30 2.5 5
PH3/As
H3
6809695 0.3 1 20 0.1 0.2
NH3 HC 6809645 300 1000 1000 50 100
NH3 LC 6809680 50 100 300 12.5 25
NH3 FL 6813260 50 100 300 12.5 25
NH3 TL 6813095 50 100 300 12.5 25
NH3 TH 6800055 300 1000 1000
0
50 100
Ozon 6814005 0.5 1 5 0.1 0.2
Part Part number
Splash Guard 6812510
Calibration Adapter V 6810536
Gasing Adapter 6806978
Mounting brackets 8326497
Part Part number
Cable gland (M20 x 1.5) 8314595
Cable gland (1.5’’) 8326479
O-ring 8326457
Counter-nut 1390139
Screw plug 8326456
Spare Parts Kit Remote
CatEx Sensor Connection
8326496
Region Part number
Brazil 8326448
European Union /Russian
Federation
8326449
United Kingdom 8326450
U. S. A. 8326451
Australia 8326452
Sensor Part number
Range
Default
value
Min. Defa
ult
Max.
A1 A2
