Dräger Polytron 8100

34 Dräger Polytron 8100
Factory default settings
7 Factory default settings
7.1 Settings which can be changed via the menu
Menu Factory Default Setting Range
Relay active on alarm / No alarm Active on alarm On / Off
A1 Alarm Depending on the sensor
A2 Alarm Depending on the sensor
A1 alarm: direction
(falling for DrägerSensor O2)
Rising Falling / Rising
A2 alarm: direction Rising
A1 latch mode Non-latching Latching / Non-Latching
A2 latch mode Latching
A1 acknowledgement mode Acknowledgeable Acknowledgeable / Not acknowledgeable
/ Pre-acknowledgeable
A2 acknowledgement mode Not acknowledgeable
Normal operation A1 relay Energized Energized / Not energized
Normal operation A2 relay Energized
Hysteresis for A1 alarm at direction rising 0 0 to A1
Hysteresis for A2 alarm at direction rising 0 0 to A2
Calibration password _ _ _1
Settings password _ _ _2
LCD setting On On / Off
SIL status Off On / Off
Language EN DE / EN / FR / ES / RU / ZH
Fault current 1.2 mA 0 to 3.5 mA
Warning Off On / Off
Warning current 3.0 mA 0 to 3.5 mA
Warning cycle time T1 10 sec 5 to 60 sec.
Warning cycle time T2 1 sec 1 to 59 sec.
Maintenance static Static / Dynamic
Maintenance current 3.4 mA 0 to 3.5 mA
Analog offset 0 mA - 0.2 to 1.5 mA
HART address 0 0 to 15
Auto-calibration Off On / Off
Calibration interval Depending on sensor 0 to 720
Function key Faults Graph, fault, warning, vitality, bump test
