Technical data
Dräger Polytron 8100 41
10.2 Marking
The marking is reproduced on a separate piece of paper
shipped with the instrument.
Serial Number key: The third letter of the serial number
specifies the manufacturing year: A = 2009, B = 2010,
C = 2011, D = 2012, E = 2013, F = 2014, H = 2015, J = 2016,
K = 2017, etc.
Example: Serial Number ARCB-0103: the third letter is C,
which means that the unit was manufactured in 2011.
10.3 Signal transmission to central controller
10.3.1 Analog signal
10.3.2 HART digital communication
10.4 Power supply and relays
10.5 Physical specifications
10.6 Environmental parameters
10.7 Environmental influences
For influences on the measurement performance and
restrictions of a particular sensor see sensor data sheet.
NOTICE
The table shows the response of the sensor to other
gases than the target gas (cross sensitivities). The
listed values are typical and are valid for new sensors.
The table does not claim to be complete. Gas mixtures
can be displayed as the sum of all components.
Gases with a negative cross sensitivity can cancel out
a positive sensor signal. The influence of the O
2
displacement is not taken into account (partial
pressure measurement).
Example:
2 Vol% ethylene in the air - cross sensitivity (table
value) = -1 Vol% O
2
.
O
2
displacement caused by 2 Vol% ethylene (2% of 20
Vol% O
2
) = -0.4 Vol% O
2
Instrument display (20.9 - 1 - 0.4) = 19.5 Vol% O
2
.
CAUTION
The exposure to higher concentrations of unsaturated
hydrocarbons, alcohols or hydrogen over an extended
period of time (dose approx. 100,000 ppm x hours)
could cause the sensor to fail.
NOTICE
Frequency of measurement calculation: 1 x per
second (update of display, analog interface and
relays).
Description Analog output
Normal operation 4 to 20 mA
Drift below zero 3.8 to 4 mA
Measuring range exceeded 20 to 20.5 mA
Instrument fault 1.2 mA
Fault on analog interface > 21 mA
Maintenance signal 3.4 mA steady signal or 1 Hz
modulation between 3 and
5 mA (selectable)
Operating voltage 10 to 30 VDC at the instrument
Cable specification 3-core shielded cable
Inrush current 2.3 A for 2 ms at 24 VDC, 10 Ω
resistor
Operating current
(max.)
80 mA at 24 VDC, without relay, non-
remote sensor
100 mA at 24 VDC, with relay, remote
sensor
Relay rating (option) SPDT, 0.1 A - 5 A at 230 VAC,
0.1 A - 5 A at 30 VDC, resistive load.
For safety-related applications (SIL 2),
the maximum contact rating is reduced
(see Dräger Polytron 8X00 Safety
Manual).
Enclosure
material
copper free aluminum or
316 stainless steel
Enclosure
protection
NEMA 4X and IP 65/66/67
Display Resolution 128 x 64 pixel, back-lit
Size (LxWxD, approx.)
Without Docking Station
7.1” x 5.8” x 5.1” (180 x 150 x 130 mm)
With Docking Station
7.3” x 7.1” x 7.4” (185 x 180 x 190 mm)
Weight (approx.)
Without Docking Station
aluminum 4.9 lbs. (2.2 kg)
stainless steel 316 8.8 lbs. (4.0 kg)
With Docking Station
aluminum 7.7 lbs. (3.5 kg)
stainless steel 316 11.9 lbs (5.4 kg)
Pressure 20.7 to 38.4 in. Hg (700 to 1300 hPa)
Humidity 0 to 100 %RH, non-condensing
Temperature -40 to +149 °F (-40 to +65 °C)
Storage temperature -4 to +149 °F (-20 to +65 °C)
See sensor data sheet for sensor specifications.
