Description
2 Description
2.1 Product overview
2.1.1 Explosion proof instrument
1 Enclosure lid
2 Handle
3 Bucket with main electronics (and optional relay)
4 Enclosure bottom
5 Sensor
6 Assembled instrument
2.1.2 Explosion proof instrument with increased safety
wiring compartment (Docking Station)
1 Enclosure lid
2 Handle
3 Bucket with main electronics (and optional relay)
4 Enclosure bottom
5 Sensor
6 Feed-through cable
7 Docking Station
8 Assembled instrument
4
6
1
3
5
2
00133298.eps
4
8
1
6
7
3
5
2
00633298.eps
