Dräger Polytron 8100

42 Dräger Polytron 8100
Technical data
10.8 Tightening torque for instrument threads
The values are valid for aluminum and stainless steel
316 versions.
10.9 Tightening torque and size for field wiring
terminals
Part Torque Lb. In. Torque Nm
Enclosure lid min. 44,3 min. 5
Sensor min. 266 min. 30
Blind plug min. 266 min. 30
Feed-through
Conduit hub
min. 443 min. 50
Instrument to
Docking Station
(4 screws)
71 8
Terminal Torque
Lb. In.
Wire size
AWG
Wire size
mm
2
Power supply
and signal
4.4 - 7.0
(0.5 - 0.8 Nm)
24 - 12 0.2 - 2.5
Relay
4.4 - 7.0
(0.5 - 0.8 Nm)
20 - 12 0.5 - 2.5
