B-9
APPENDIX B/ Technical Specifications
Parameter Settings in Each Monitoring Mode
Setup
parameters
The following table lists the default settings for the threshold parameters in each
monitoring mode.
Continued on next page
Parameters
Standard
Power
Quality
Current
Inrush
Fault
Recorder
Long-term
Timed
Recording
Continuous
Data
Logging
EN50160
RMS Variation
High Limit 110% 120% 110% Off Off 110%
Low Limit 90% Off 90% Off Off 90%
Very Low
Limit
10% Off 10% Off Off 1%
RMS Pre-
trigger (cycles)
644 0 1 6
RMS In-Out
Post-trigger
(cycles)
6 200 100 10 (50 Hz);
12 (60 Hz)
26
RMS Out-In
Post-trigger
(cycles)
6 200 1000 10 (50 Hz);
12 (60 Hz)
26
Waveform
Capture Pre-
trigger (cycles)
244 0 1 2
Waveform
Capture Post-
trigger (cycles)
2 200 1000 10 (50 Hz);
12 (60 Hz)
22
Transients
Absolute
Instantaneous
Peak
170% 350% 170% Off Off 170%
Cycle-by-cycle
Waveshape
Magnitude
10% Off 10% Off Off 10%
Cycle-by-cycle
Waveshape
Duration (% of
cycle)
10% Off 10% Off Off 10%
Waveform
Duration
7% Off 7% Off Off 7%
