Dranetz PowerGuide 4400 User Manual

B-10
Parameter Settings in Each Monitoring Mode, continued
Setup
parameters
(continued)
The following table lists the default settings for the threshold parameters in each
monitoring mode.
*Numbers are in percent of nominal unless otherwise specified.
Parameters
Standard
Power
Quality
Current
Inrush
Fault
Recorder
Long-term
Timed
Recording
Continuous
Data
Logging
EN50160
Waveform Capture Trigger Response
When Volts
go out,
record:
All Active
Channels
Off All Active
Volt
Channels
Off Off All Active
Channels
When Amps
go out,
record:
Fault
Amps
Channels
Fault
Amps
Channels
Fault
Amps
Channels
Off Off Fault
Amps
Channels
Journal Intervals
Volts 10 minutes Off Off 10 minutes 1 second 10 minutes
Amps 10 minutes Off Off 10 minutes 1 second 10 minutes
Power 10 minutes Off Off 10 minutes 1 second 10 minutes
Demand 15 minutes Off Off 15 minutes Off 15 minutes
Energy 10 minutes Off Off 10 minutes Off 10 minutes
Harmonics 10 minutes Off Off 10 minutes Off 10 minutes
Flicker (Pst) 10 minutes Off Off 10 minutes Off 10 minutes
Flicker (Plt) 2 hours Off Off 2 hours Off 2 hours
Characterizer
Mode
IEEE 1159 None None IEEE 1159 None IEC
61000-4-30
