Vigor2120 Series User’s Guide
260
4
4
.
.
9
9
.
.
7
7
W
W
a
a
k
k
e
e
o
o
n
n
L
L
A
A
N
N
A PC client on LAN can be woken up by the router it connects. When a user wants to wake up
a specified PC through the router, he/she must type correct MAC address of the specified PC
on this web page of Wake on LAN (WOL) of this router.
In addition, such PC must have installed a network card supporting WOL function. By the
way, WOL function must be set as “Enable” on the BIOS setting.
Available settings are explained as follows:
Item Description
Wake by
Two types provide for you to wake up the binded IP. If you
choose Wake by MAC Address, you have to type the
correct MAC address of the host in MAC Address boxes. If
you choose Wake by IP Address, you have to choose the
correct IP address.
IP Address
The IP addresses that have been configured in
Firewall>>Bind IP to MAC will be shown in this drop
down list. Choose the IP address from the drop down list
that you want to wake up.
MAC Address
Type any one of the MAC address of the bound PCs.
Wake Up
Click this button to wake up the selected IP. See the
following figure. The result will be shown on the box.
